JZ-726 Multi-Function High-Capacity Automated Controls Common Rail Test Bench for EUI EUP HEUI Testing

Product Introduction

JZ-726 is a versatile and high-capacity test bench that can handle a wide range of fuel system components from the Euro-3 to Euro-6 emission standards. Its automated controls and extensive testing capabilities make it a useful tool for repair and maintenance of modern diesel fuel systems. It can test thousands of electronic unit injectors and electronic unit pumps, and the experimental data are complete. Jz-726 Diagnostic Multi-Function Eui Eup Heui All in One Common Rail Test Bench
 Jz-726 Diagnostic Multi-Function Eui Eup Heui All in One Common Rail Test Bench
Functions Description

Standard functions:


1. Test unit injectors (EUI)
2. Test unit pumps (EUP)
3. Testing HEUI injectors

4. Test smart injectors


Optional Functions:
1. Test X15, Q60 single HPI
2. Test common rail oil pump

Hardware Configuration:

1. Fuel tank oil level lower limit alarm
2. Real-time display injection/return curves
3. Test oil automatic heating/cooling control
4. Equipped multiple high-precision filters



Product Details

Jz-726 Diagnostic Multi-Function Eui Eup Heui All in One Common Rail Test BenchJz-726 Diagnostic Multi-Function Eui Eup Heui All in One Common Rail Test BenchJz-726 Diagnostic Multi-Function Eui Eup Heui All in One Common Rail Test Bench
Jz-726 Diagnostic Multi-Function Eui Eup Heui All in One Common Rail Test BenchJz-726 Diagnostic Multi-Function Eui Eup Heui All in One Common Rail Test Bench
Technical Parameters
Technical Parameters
Output7.5 KW
Power3-Phase 4-Wire  380V 50/60HZ
Rail Pressure0~2700 Bar
Rail Pressure Precision±5 Bar
Oil Tank VolumeDiesel: 20L
Engine: 20L
Fuel Temperature40±2ºC
Filter Precision<  5μm
Gross Weight1030 kg
Packing Size2000*1200*1950 mm
Speed Control ModelFrequency Converter
Temperature Control SystemAir Conditioning Heat Dissipation
Nozzle SensorImported Original Elliptical Type Flow Sensor
Fuel Pump SensorImported Original Vane Type Flow Sensor
LanguageEnglish, Spanish, Russian,etc
MaterialMetal Plate
PaintingPowder Painting, Durable
ColorGreen (can be customized)
LogoJing Zheng Hong Ye (can be customized)
MOQ1 Piece
Payment40% Deposit, the rest paid before shipment
Warranty Time12 months
Delivery time30 days after prepaid
Shipping PackingWooden Case

Testing Scope
Jz-726 Diagnostic Multi-Function Eui Eup Heui All in One Common Rail Test Bench



Related Products
Jz-726 Diagnostic Multi-Function Eui Eup Heui All in One Common Rail Test Bench

Our Company

Jz-726 Diagnostic Multi-Function Eui Eup Heui All in One Common Rail Test Bench
ExhibitionJz-726 Diagnostic Multi-Function Eui Eup Heui All in One Common Rail Test Bench
Jz-726 Diagnostic Multi-Function Eui Eup Heui All in One Common Rail Test Bench


Why Choose Us

1.  Our company has our own maintenance center with an area of 1200 square meters. It has been servicing the diesel fuel engine system for 20 years. Rich maintenance experience, let our products pay more attention to solving the difficult problems in maintenance.
2.  Independent design and development team,and produce experience.
3.  Almost all important parts of the equipment are come from top suppliers in the industry, such as DRV, common rail tube, CP3 pump, from original of B-osch.
4. Strict QC,  good pre-sale and after-sale service, Providing remote assistance services free.
5. Customized according to customer requirements, such as appearance, color, etc.
